5754 Aluminum Sheet
Short description:
- TEMPER: H111,H112
- THICKNESS: 1-30mm (ready stock)
- WIDTH: 1250-1500mm ; LENGTH: 2500-3000mm
- CUTTING: Cut to size ( ≥8 mm thickness),
- OTHERS: Material traceability, Mass-stock，Fast shippment
Product description:
Chemical composition of 5754 aluminum alloy
- Aluminum (Al): balance
- Silicon (Si): 0.4% max
- Ferrum (Fe): 0.4% max
- Copper (Cu): 0.1% max
- Manganese (Mn): 0.5% max
- Magnesium (Mg): 2.6-3.6%
- Chromium (Cr): 0.3% max
- Zinc (Zn): 0.2% max
- Titanium (Ti): 0.15% max
- Other elements: Each 0.05% max, Total 0.10% max
Typical mechanical properties of 5754 aluminum
- Tensile strength: 190-260 MPa
- Yield strength: 100-240 MPa
- Elongation: 12-25%
- Hardness (Brinell): 55-80 HB
(The values are typical or min values,for reference only.)
| PLACE OF ORIGIN | China |
|---|---|
| STANDARD | GB/T(default),ASTM,AMS,EN |
| MATERIAL CERTIFICATES | Material test report, and other certificates |
| SAMPLE | Support small sample (Chargeable) |
| PROCESSING SERVICE | Cutting, bending, CNC, anodizing, etc. |
| MOQ | Small MOQ with ready stock,even a piece. |
| LOGISTICS MODE | Express, by Land，by Air，by sea |
| SHIPPING PORT | Shanghai(default) |
| PAYMENT OPTIONS | TT, PayPal, L/C at sight, Pay on Alibaba |
| PACKAGING | Pallet(default), Wooden box(Chargeable) |
| LEAD TIME | 2-7 days for ready stock.Or mutual agreement |
| CUSTOMIZATION | Can be customized according to customer’s requirement |
| ABOUT PRICE | Fluctuate with aluminum prices & USD exchange rate |
About 5754 Aluminum Sheet:
5754 aluminum sheet is a medium-strength alloy with excellent corrosion resistance and good weldability. It is widely used in marine applications and in the construction of transportation vehicles. It has good formability, high fatigue strength, and high dimensional stability. The alloy also has excellent resistance to stress corrosion cracking and can withstand high-pressure applications. Additionally, 5754 aluminum sheet has good machinability and is easy to polish, making it a popular choice for decorative applications. Overall, it is a versatile alloy that offers excellent performance in a wide range of applications.
