Aluminum tube pipes
Short description:
- TYPE: Extruded Aluminium tube / pipe
- GRADE: 6063 T5 / 6061T6
- OD: 8-550mm ,WT: 1-50mm
- LENGTH: 3000 / 6000mm, Cut to short size
- OTHERS: Material traceability, Mass-stock,Fast shippment
- CUSTOMIZATION: Contact to us
Product description:
Chemical composition of 6061 aluminum alloy
- Aluminum (Al): balance
- Silicon (Si): 0.4-0.8%
- Ferrum (Fe): 0.7% max
- Copper (Cu): 0.15-0.4%
- Manganese (Mn): 0.15% max
- Magnesium (Mg): 0.8-1.2%
- Chromium (Cr): 0.04-0.35%
- Zinc (Zn): 0.25% max
- Titanium (Ti): 0.15% max
- Other elements: Each 0.05% max, Total 0.15% max
Chemical composition of 6063 aluminum alloy
- Aluminum (Al): balance
- Silicon (Si): 0.4-0.6%
- Ferrum (Fe): 0.35% max
- Copper (Cu): 0.1% max
- Manganese (Mn): 0.1% max
- Magnesium (Mg): 0.45-0.9%
- Chromium (Cr): 0.1% max
- Zinc (Zn): 0.1% max
- Titanium (Ti): 0.1% max
- Other elements: Each 0.05% max, Total 0.15% max
(The values are typical or min values,for reference only.)
| PLACE OF ORIGIN | China |
|---|---|
| STANDARD | GB/T(default),ASTM,AMS,EN |
| MATERIAL CERTIFICATES | Material test report, and other certificates |
| SAMPLE | Support small sample (Chargeable) |
| PROCESSING SERVICE | Cutting, bending, CNC, anodizing, etc. |
| MOQ | Small MOQ with ready stock,even a piece. |
| LOGISTICS MODE | Express, by Land，by Air，by sea |
| SHIPPING PORT | Shanghai(default) |
| PAYMENT OPTIONS | TT, PayPal, L/C at sight, Pay on Alibaba |
| PACKAGING | Pallet(default), Wooden box(Chargeable) |
| LEAD TIME | 2-7 days for ready stock.Or mutual agreement |
| CUSTOMIZATION | Can be customized according to customer’s requirement |
| ABOUT PRICE | Fluctuate with aluminum prices & USD exchange rate |
About Aluminum tube pipes：
Aluminum tube pipes are hollow cylindrical sections made from aluminum alloy materials. They are widely used in various industries, such as aerospace, automotive, construction, and manufacturing. Aluminum tubes are lightweight, corrosion-resistant, and have good thermal conductivity, making them suitable for a range of applications.
There are two main types of aluminum tubes: extruded and drawn. Extruded tubes are made by pushing a heated aluminum billet through a die to create the desired shape, while drawn tubes are made by pulling an aluminum rod through a die to form the tube.
Aluminum tubes come in different sizes and shapes, including round, square, and rectangular. They can also be customized to meet specific requirements, such as different wall thicknesses, lengths, and surface finishes. Additionally, aluminum tubes can be further processed to produce components such as pipe fittings, connectors, and couplings.
